瀝青/TPO拼塊地毯生產線
主要技術參數 main technical parameters
公稱幅寬 Width | 120/220cm可調（有效幅寬100/200cm） 120/220cm adjustable(valuable width is 100/200cm) |
| 機械速度 Mechanical speed | 1~10m/min變頻調速 1~10m/min frequency control |
方塊尺寸 Tile size | 50cm×50cm、 50cm×100cm、 25cm×100cm、 100cm×100cm、多邊形Polygon |
| 傳動方式 Transmission mode | 輸送鏈條 transmission chain |
熱源 Heating source | 導熱油 (20萬大卡供油溫度250℃） conduction oil (200,000 kilocalories at 250℃) |
烘箱溫度 Oven temperature | 100~200℃自動溫控 auto constant temp. control from 100 to 200℃ |
冷卻溫度Cooling temperature | 20~60℃自動冷卻控溫 auto water-cooling temp.control from 20~60℃ |
整機功率 Total power | ≈45KW 全自動≈60KW approx.45KW, approx.60KW with full auto operation |
生產方式Operating mode | 分切/全自動連續生產 Separate cutting/full auto continuous production |
產品用途
適用于簇絨或針刺、尼龍或丙綸地毯的背面涂瀝青/TPO、支底、凝固以及自動切塊等流水生產線
Intended for tufting, knitting, and nylon or PP fibre carpet backing bitumen/TPO, subbase, drying as well as auto tile cutting production line.
